Product Highlights

SAE J1455 Compliant

  • Built to withstand the extreme driving environment of a commercial vehicle

Weather Band

  • Offers 7 weather band frequencies/channels free-of-charge to provide continuous weather information 24/7

Front Auxiliary Input (Music Port)

  • Allows a driver to plug in a smart device and play digital music files through the vehicle's built-in speakers

Rear Auxiliary Input

  • Provides an auxiliary terminal for permanent hard wire to the rear side of the radio

SAE J1939 Compliant

  • Allows different vehicle components that run the communication bus system to talk to each other; compatible with most digital steering wheel/rear sleeper controls

ISO Connector

  • Allows the radio to be connected directly to the vehicle's harness; no other harness is required - no cutting, no separate accessories to purchase for vehicles manufactured with the ISO connect harness

Direct Antenna Connect

  • Direct connect for an AM / FM / WB radio antenna; and on SAT-integrated radio models - a direct connect for Satellite radio antenna

Sound Quality (EQ) Function

  • Select the sound type (Pop, Rock, Country, News, Jazz, Classical, or Manual)

Separate Bass, Mid, Treble, Balance and Fader Controls

Built-In Quartz Alarm Clock with One Hour Timer

Output Power - 18 Watts x 4 Channels

6 AM / 12 FM Preset Buttons

Top Movers - Delphi Radios

PART NUMBERBUTTON BACKLIGHTING COLORFRONT PANEL USB PORTIPOD CONTROL / COMMAND30 DAY CLOCK MEMORYSATELLITE RADIOAM / FM PRESETSSAT PRESETSMP3 / WMA PLAYBACKCD-R / CD-RW PLAYBACKBLUETOOTH
PP105221GREENYESYESNONO6 / 12NONO / NONOYES
PP105222GREENNONONONO6 / 12NOYES / YESYESNO
PP105224GREEN OR AMBERYESYESNONO6 / 12NOYES / YESYESYES
PP105226GREEN OR AMBERYESYESNOYES6 / 1218YES / YESYESYES
PP105711GREEN OR AMBERYESYESYESNO6 / 12NONO / NONOYES
PP105713GREEN OR AMBERYESYESNONO6 / 12NOYES / YESYESNO
PP105715GREEN OR AMBERYESYESYESYES6 / 1218YES / YESYESYES
PP107088GREEN OR AMBERYESYESYESYES6 / 1218NO / NONONO
PP107091AMBERYESYESYESNO6 / 12NOYES / YESYESYES
PP107092AMBERYESYESYESYES6 / 1218YES / YESYESYES

Product Highlights

Front Auxiliary Input (Music Port)

  • Allows a driver to plug in a smart device and play digital music files through the vehicle’s built-in speakers

Direct Antenna Connect

  • Direct connect for an AM / FM / WB radio antenna; and on SAT-integrated radio models – a direct connect for a Satellite radio antenna

Sound Quality (SQ) Function

  • Select the sound type (Flat, Rock, Pop, or Vocal)

Separate Bass, Mid, Treble, Balance and Fader Controls

Built-In Quartz Alarm Clock

Output Power - 45 or 50 Watts x 4 Channels

6 AM / 18 FM Preset Buttons

LED Display Lighting

Top Movers - Panasonic Radios

PART NUMBERDISPLAY COLORBUILT-IN ALARM CLOCKUSB INPUTIPOD CONTROL (BUILT-IN)IPOD PANDORA CONTROL (USB)SATELLITE RADIO (WITH ADAPTER)SATELLITE RADIO (BUILT-IN)NOAA WEATHERBANDAM / FM PRESETSMP3 / WMA PLAYBACKBLUETOOTH
CQ5109UGREENYESNONONOYESNOYES6 / 12YES / NONO
CQCX160UGREENNONONONONONONO6 / 12YES / NONO
CQRX660UREDNOYESYESYESNONONO6 / 12YES / YESNO
CRSM4208UGREENYESYESYESNONOYESYES6 / 12NO / NOYES

General Product Information

 Delphi and Panasonic radios:

  • Can be ordered for all-makes applications at no additional charge
  • Are designed specifically for heavy duty trucks and are not sold through retail stores
  • Are available with a 3-year extended warranty for fleet applications (certain models)
  • Offer built-in SiriusXM® Satellite Radio tuners (certain models)

Warranty Information

Delphi

  • ONE YEAR OF WARRANTY COVERAGE - One year warranty with the purchase of all Delphi Radios

Panasonic

  • ONE YEAR OF WARRANTY COVERAGE - One year warranty with the purchase of all Panasonic Radios
