Assured Quality Standards: Rigorous inspection of every component after complete disassembly and cleaning. Ambient & hot tested to validate performance in simulated operating temperatures.
Industry Leading: Original components or validated equivalents for cab and frame mounted models are used in the reassembly process. Industry leading processes establish customer confidence in product quality and
reliability.
Nationwide Availability: Proudly remanufactured in the USA and available at over 800 locations.
Warranty: We stand behind our product with 1-year / unlimited miles.
Cost of Ownership: A Reman option provides an economical choice while maintaining the same standards and functionality as Genuine.
Comprehensive Testing: Functionally tested with the latest software and reset to original defaults. Voltage-tested to ensure proper readings at both elevated and reduced voltage levels. Internal drivers are load-tested to ensure they are functioning at full power. Sensor inputs are tested and driven through all
operating ranges.
Cross References: Reman part numbers cross referenced below to the Genuine part numbers for ordering ease and accuracy.
| Genuine Part Number | Detroit Reman Part Number | Part Description |
|---|---|---|
| WAB 400 860 000 0 | DDR 400 860 000 0R | REMAN PABS ECU E4F 12V |
| WAB 400 864 009 0 | DDR 400 864 009 0R | REMAN PABS ECU E4C 12V 4S4M PLC W/ ATC O |
| WAB 400 864 624 0 | DDR 400 864 624 0R | REMAN PABS ECU-ABS,4S4M,E-CAB,HSA |
| WAB 400 864 701 0 | DDR 400 864 701 0R | REMAN PABS ECU,4S/4M,HSA,ATC,4.6 |
| WAB 400 865 043 0 | DDR 400 865 043 0R | REMAN PABS -ECU E4C 12V |
| TDA S400 864 088 0C | DDR S400 864 088 0R | REMAN PABS -ECU E4C 12V 4S4M |
| TDA S400 864 011 0C | DDR S400 864 011 0R | REMAN PABS-ECU E4C 12V 4S4M |
| WAB 400 865 301 0 | DDR 400 865 301 0R | REMAN PABS ECU,4S/4M,HSA,RSC,4.6 |
| WAB 400 864 522 0 | DDR 400 864 522 0R | REMAN PABS -ECU E4C 12V 4S4M PLC |
| TDA S400 868 101 0 | DDR S400 868 101 0R | REMAN PABS ECU-4S4M,RSC,E4.4B,FRM |
| WAB 400 867 071 0 | DDR 400 867 071 0R | REMAN ECU-ABSE8C 12V 4S4M XBR ESC ATCPLC |
| WAB 400 867 072 0 | DDR 400 867 072 0R | REMAN ECU-ABSE8C 12V 4S4M XBR HAS ATCPLC |
| WAB 400 867 073 0 | DDR 400 867 073 0R | REMAN ECU-ABS ESC 12V 6S4M XBR ESC |
| WAB 400 867 074 0 | DDR 400 867 074 0R | REMAN ECU-PABS E8C 12V 6S4M XBR |
| WAB 400 867 075 0 | DDR 400 867 075 0R | REMAN ECU-ABS E8C 12V 6S6M XBR ESC ATCPL |
| WAB 400 867 076 0 | DDR 400 867 076 0R | REMAN ECU-ABS E8C 12V 6S6M XBR HAS ATCPL |
| WAB 400 867 079 0 | DDR 400 867 079 0R | REMAN ECU-PABS E8C 12V 6S6M HSA |
| WAB 400 867 101 0 | DDR 400 867 101 0R | REMAN MODULE-ECU,ABS,WAB,4S/4M,ATC,ESC |
| WAB 400 867 102 0 | DDR 400 867 102 0R | REMAN MODULE-ECU,ABS,WAB,4S/4M,ATC,HSA,E |
| WAB 400 867 104 0 | DDR 400 867 104 0R | REMAN MODULE-ECU,ABS,6S/6/4M,ATC,ESC,HSA |
| WAB 400 867 113 0 | DDR 400 867 113 0R | REMAN ECU MBSP 12V 4S4M ESC ATC PLC |
| WAB 400 867 114 0 | DDR 400 867 114 0R | REMAN ECU MBSP 12V4S4M HSA ESC |
| WAB 400 867 116 0 | DDR 400 867 116 0R | REMAN ECU MBSP 12V 6S HSA ESC ATC PL |
Warranty: We stand behind our product with 1-year / unlimited miles.
