Alliance Clutch Program
The most complete line of NEW clutch assemblies, supplemental clutch parts and flywheels for class 6, 7 & 8 vehicles.
2023 Alliance Clutch Catalog
Alliance Tranmission & Clutch Bundle
2023 DTNA Parts DPC - Alliance Clutch_Detroit REMAN DT12 Presentation
2023 DTNA Parts DPC Alliance Clutch Detroit DT12 Presentation
Product Highlights
NEW Clutches, No Core
Made in the USA
OEM Quality
Heavy Duty Clutches – 2 Years, Unlimited Mile Warranty
Extended Clutch Warranty - 3 Years Unlimited Miles = IATCO Clutch + IATCO Clutch Installation Kit
Medium Duty Clutches – 1 Year, Unlimited Mile Warranty
Top Movers - Alliance Clutch Assemblies
| Alliance Part Number | O.E.M. Reference | Part Description |
|---|---|---|
| ABP N25 208925 82 | 308925-82, 208925-82, 108925-82AM | 15-1/2" x 2" Easy Effort Clutch, Two-Plate, 4-Paddle / 7-Spring, 3600 Plate Load / 1700 Torque, Triple-Zerk |
| ABP N25 208925 20 | 308925-20, 208925-20, 108925-20AM | 15-1/2" x 2" Easy Effort Clutch, Two-Plate, 6-Paddle / 7-Spring, 4000 Plate Load / 1860-2050 Torque, Triple-Zerk |
| ABP N25 308925 25 | 308925-25, 208925-25, 108925-25AM | 15-1/2" x 2" Easy Effort Clutch, Two-Plate, 6-Paddle / 7-Spring w/ Pre-Damper, 4000 Plate Load / 2050 Torque, Triple-Zerk |
| ABP N25 208925 51 | 308925-51, 208925-51, 108935-51AM | 15-1/2" x 2" Easy Effort Clutch, Two-Plate, 4-Paddle / 9-Spring, 3600 Plate Load / 1760 Torque, Triple-Zerk, MACK |
| ABP N25 209701 51 | 309701-51, 209701-51, 109701-51AM | 15-1/2" x 2" AutoSet Clutch®, Two-Plate, 4-Paddle / 9-Spring, 3600 Plate Load / 1760 Torque, Triple-Zerk, MACK |
| ABP N25 209701 82 | 309701-82, 209701-82, 109701-82AM | 15-1/2" x 2" AutoSet Clutch®, Two-Plate, 4-Paddle / 7-Spring, 3600 Plate Load / 1700 Torque, Triple-Zerk |
| ABP N25 309701 25 | 309701-25, 209701-25, 109701-25AM | 15-1/2" x 2" AutoSet Clutch®, Two-Plate, 6-Paddle / 7-Spring w/ Pre-Damper, 4000 Plate Load / 2050 Torque, Triple-Zerk |
| ABP N25 122002 35A | 122002-35A | 15-1/2" x 2" MaxShift Clutch®, Two-Plate, 6-Paddle / 7-Spring (Pre-Damper), 4200 Plate Load / 1850 Torque, 14-Spline, Incl. Clutch Brake |
| ABP N25 107237 10 | 107237-10 | 14" x 1-3/4" Stamped Steel Clutch, Two-Plate, 3-Paddle / 8-Spring, 2000 Plate Load / 900 Torque, Includes Positive Separator Pin |
| ABP N25 104100 2 | 104100-2 | 365mm x 1-3/4" Stamped Steel Clutch, Single-Plate, 3-Paddle / 8-Spring, 3200 Plate Load / 660 Torque, Sealed Bearing |
Top Movers - Supplemental Clutch Parts, Clutch Installation Kits, Flywheels
| Alliance Part Number | O.E.M. Reference | Part Description |
|---|---|---|
| ABP N25 A0032502115 | A 003 250 21 15, 6482 000 218, K-4515CL | DT12 Clutch Actuator |
| ABP N25 K2468 | K-2468 | Clutch Installation Kit, RT Series |
| ABP N25 K4125 | K-4125 | Clutch Installation Kit, RT Series (w/ Hydraulic Fork) |
| ABP N25 K3600 | K-3600 | Clutch Installation Kit, FR Series |
| ABP N25 K4124 | K-4124 | Clutch Installation Kit, FR Series (w/ Hydraulic Fork) |
| ABP N25 K4145 | K-4145 | Clutch Installation Kit, UltraShift Plus |
| ABP N25 127760 | 127760 | 2" Torque Limiting Clutch Brake |
| ABP N25 BK313 | BK-313 | 2" Hinged Clutch Brake |
| ABP N25 105C137 | 105C-137 | Standard Clutch Fork |
| ABP N25 A7786 | A-7786 | Hydraulic Clutch Fork |
| ABP N25 23514177 | 23514177 | Flywheel, Detroit Series 60 |
| ABP N25 A472030110572 | A472 030 11 05 | Flywheel, DD15 |
| ABP N25 3680922 | 3680922 | Flywheel, Cummins ISX Signature 600 |
General Product Information
Detailed product description
The most complete line of NEW clutch assemblies, supplemental clutch parts and flywheels for class 6, 7 & 8 vehicles.
Warranty Information
Heavy Duty Clutches – 2 Years, Unlimited Mile Warranty
Extended Clutch Warranty - 3 Years, Unlimited Miles = Alliance Clutch + Alliance Clutch Installation Kit
